5 Lighting Control Wiring Diagrams – Bundle

Everything you need to wire any standard lighting control scenario — in one complete bundle. Five professional-grade diagrams covering the most common configurations, ready to use on the job or in your designs.

What's Included (5 Diagrams)

• Single-pole switch — the everyday standard
• 3-way switch — two-location control
• 4-way switch — three or more locations
• Dimmer switch wiring — single and multi-location
• Motion sensor / occupancy sensor wiring — line-voltage and low-voltage configurations

File Formats

• PDF (print-ready, high resolution)
• Editable Visio (.vsdx)
• PNG (high-res, for reports and documentation)

Who It's For

Electrical contractors, designers, facility managers, and advanced DIYers who need accurate, professional wiring diagrams they can use immediately or adapt for their own projects.

Format: Instant download — ZIP archive containing all 5 diagrams in PDF, Visio, and PNG formats.
